Marmitek MegaView 66 - HDMI & RC over single CAT5/6

Marmitek MegaView 66

HDMI extender over single CAT5

The Marmitek MegaView 65/66 enables you to easily extend an HDMI (High Definition Multimedia Interface) signal or DVI (Digital Visual Interface) over one CAT5e/6 cable. The maximum CAT5e/6 cable length is 60 metres at 1080p resolution. Supports 1080p Full HD and 3D resolutions, without compression! Watch TV programmes or films and view photos from, for example, your digital TV decoder, Media Centre PC, Bluray player or hard disk recorder anywhere in the home on your TV/projection screen, in HD quality. The MegaView 66 allows you to operate the connected device from another room or through closed cabinet doors using your own remote control.

All Marmitek products are manufactured with the utmost precision and are of high quality.

Feautures of hdmi extender

• Watch your HD Content elsewhere on your TV.
• Watch films, view photos or listen to music stored on, for example, your digital TV decoder, Media Center PC, Blu-ray player or hard disk recorder on your TV/ projection screen, in perfect HD quality.
• Extend your HDMI cable up to 60 metres using one CAT5e/CAT6 cable!
• Supports 1080p Full HD and 3D resolutions, without compression!
• Use of CAT5e/CAT6 cabling results in optimum price/ quality ratio.
• Operate your connected A/V equipment remotely, using the infrared return function.

How it works?

Connect the HDMI source (Blu-ray disc player, TV Decoder, Media Centre PC, etc.) to the MegaView 65/66 transmitter, using an HDMI cable (not provided). Connect the MegaView 65/66 receiver to the appliance shown (e.g. HDTV or projector), using an HDMI cable (not provided). Use one CAT5e/6 Ethernet cable to connect the MegaView 80’s transmitter to the receiver. Attention! The MegaView 65/66™ cannot be connected to an existing home network (LAN), this may cause damage to the device.. Finaly, connect the power adapter on the ‘DC/5V’ connection on the MegaView 65/66 and plug the adapter into a socket.

Features

Video

Supported HDTV resolutions: 480i@60Hz,480p@60Hz,576i@50Hz, 576p@50Hz,720p@50/60Hz, 1080i@50/60Hz,1080p@50/60/30/24Hz

Maximum Pixel Frequency (max): 225 MHz

Maximum Bit Rate (max): 7.75 Gbps (2.25 Gbps per channel)

Supported 3D formats: 720p@59.94/60/50Hz, 1080p@23.98/24/30Hz

Audio

Supported audio formats: PCM stereo.

Trasmitter

HDMI input: (19-pin female) 1 HDMI

CAT 5E/6 output : RJ45, EIA/TIA T568B

Maximum CAT5e/6 cable length: 60m@1080p

Receiver

HDMI output: (19-pin female) 1 HDMI

CAT 5E/6 input : RJ45, EIA/TIA T568B

IR Receiver (MegaView 66)

Frequency range: 20 - 60 KHz

IR reception range: ± 6 metres

Connection: 3.5mm jack plug

Cable length: 100 cm

Power

Input: 100-240VAC @50-60Hz

Output: 5VDC @ 1A

The set contents

1x transmitter (HDMI Transmitter)

1x receiver (HDMI Receiver)

2x Power adaptor

1x User Manual
