MPL - Power Supply MPL-06-24V

MPL Power MPL-06-24V

Power Supply 24V/250mA

MPL - Power Supply MPL-06-24, 24V/250mA is a power supply with 1 output and rated power: 6 W.

Features

Input voltage: 176-264V AC

Output voltage: 24V DC

Rated power: 6 W

Output current: 250mA

Cooling method: passive

Degree of protection: IP20

Dimensions: 5.2 x 4.35 x 2.1 cm (L X W X H)

Package Dimensions: 12 x 8.5 x 2.5 cm

Packaging Weight: 0.050Kg

Protections: Overload / Short circuit / Over Temperature

Cooling with free air flow

IP20 tightness class

Working temperature: -10 ° C - + 45 ° C

Technical Specifications

Input

Nominal input voltage: 230Vac ± 1%

Input voltage range: 176Vac-264Vac

Input frequency range: 47 ÷ 63Hz

Efficiency: 75%

No load power consumption (Max): 0.3W

Power factor: >0.5

Inrusch current: 15A / 230VAC

Output

Output voltage: 24V

Output current: 0.25A

Current range: 0 ÷ 0.25A

Power: 6W

Line regulation: ± 3%

Load regulation: ± 2%

Tolerance: ± 4%

Ripple & Noise (Max): < 2.4VP-P

Rise time: 50ms / 230VAC at full load

Protection

Full protection: Short circuit, overload, low battery

Operation Environment

Working temperature: -10°C ÷ 45°C
Humidity: 10 ~ 90% RH (non-condensing)

Dimensions & weight

Device Weight (g): 32g

Dimensions: 52 x 21 x 43.5mm (L x W x H)

Standards

EMC: EN55015, EN61000-3-2, EN61000-3-3, EN61547, EN61000-4-2, EN61000-4-5

The set contents

1 x MPL - Power Supply MPL-06-24V

1 x Manual (English)
