Marmitek MegaView 60 - HDMI over double CAT5/6 cable

Marmitek MegaView 60

HDMI extender over CAT5

The Marmitek MegaView 60/61 enables you to easily extend an HDMI (High Definition Multimedia Interface) signal or DVI (Digital Visual Interface) over two CAT5e/6 cables. Maximum CAT5e/6 cable length is 30-60 metres for 1080p resolution and 60-100 metres for 480p resolution. Appliances connected to this may include an HD set-top box, media center PC, HD-media player, blu-ray disk player or game console.

All Marmitek products are manufactured with the utmost precision and are of high quality.

Feautures of hdmi extender

• Watch your HD Content elsewhere on your TV.
• Watch TV programmes or films and view photos from, for example, your digital TV decoder, Media Centre PC, Blu-ray player or hard disk recorder anywhere in the home on your TV/projection screen, in perfect HD quality.
• Extend your HDMI cable up to 60 metres using two CAT5e/CAT6 cables!
• Supports up to 1080p Full HD without any loss of quality.
• Supports High Definition LPCM 7.1CH, Dolby TrueHD and DTS-HD Master Audio.


How it works?

Connect the HDMI source (HD-DVD player, blu-ray disc player, HD set-top box, game console, etc.) to the MegaView 60/61 transmitter, using an HDMI cable. Connect the MegaView 60/61 receiver to the appliance shown [2] (e.g. HDTV or projector), using an HDMI cable. Use two CAT5e/6 Ethernet cables to connect the MegaView 60/61 transmitter with the MegaView 60/61 receiver. Finaly, connect the power adapter to the ‘DC/5V’ connection on the Marmitek MegaView 60/61 receiver (HDMI Receiver) and plug the adapter into a socket.

Features

Resolution

Supported HDTV Resolutions: 480p, 576i, 576p, 720p, 1080i, 1080p

Single link Bit Rate (max): 1.65 Gbps

Supported Standards: HDMI DVI, HDCP

Trasmitter

HDMI input: (19-pin female) 1 HDMI

Video signal input: 0.5 - 1.0V p-p

DDC signal input: 5V p-p

Receiver

HDMI output: (19-pin female) 1 HDMI

Video output: HDMI V1.2a

CAT5e/6 cable length (max.): 60m for 480p and 30m for 1080p (MegaView60) 100m for 480p and 60m for 1080p (MegaView61)

Power

Input: 100-240VAC @50-60Hz

Output: 5VDC @ 2A

The set contents

1x transmitter (HDMI Transmitter)

1x receiver (HDMI Receiver)

1x Power adaptor

1x User Manual
